Application Area
Sill insulation against the foundation for exterior walls with integrated overlapping moisture protection (vapor barrier) for easy connection to the foundation slab's comprehensive moisture protection. An insulating layer between the foundation and sill, where capillary-breaking moisture protection and airtightness are desired.
Installation
For complete assembly instructions, see the separate assembly guide.
Important!
- When splicing and connecting to other moisture protection, Sealing Tape T-Flex should be used.
- The width of the sill insulation must always at least match the width of the overlying sill board.
- Storage and preservation should be done in a way that protects the product from UV radiation and heat (< +35˚C) as this shortens the product's lifespan.
- T-Syll Duo has a built-in UV protection that corresponds to the normal construction time.
Environmental Assessments
Building materials assessed for a better working environment.
Assessed by Sunda Hus for sustainable construction.
Assessed by the Building Material Assessment for sustainable and non-toxic construction.
Declared item in Supply Chain Declaration Portal (SCDP) for New buildings gen. 4.
Registered in the Swan's house product portal
This product is evaluated and registered with the following entities.
Related content
Articles
- Name Art.nr Specification
Technical specification
- Material: Expanded and extruded LD polyethylene (LDPE)
- Density: 30 kg (SS-EN 1602)
- Thickness: 7 mm
- Aging resistance: (alkali) At least 50 years (SP-0414)
- Vapor tightness (approx.): 2000 x 10³ s/m (SP-2706)
- Waterproofness: Sealed (EN 1928)
- Recommended installation temperature: -20 to +40 ˚C
Accessories for T-Syll Duo
