T-Syll
A robust, strong sill insulation with insulating, air and moisture sealing properties that has at least 50 years of aging resistance. T-Sill consists of expanded polyethylene in the form of a foam. The foam consists of completely closed and insulating cells.
Åldersbeständig minst 50 år
Lufttätande och fuktskyddande
Leveling and insulating
Application Area
T-Syll ger ett isolerande skikt mellan grund och syll, där kapillärbrytande fuktskydd och lufttäthet vill uppnås. T-Syll används som syllisolering mot grund för yttervägg och fungerar utjämnande mot underlaget.
Installation
For complete assembly instructions, see the separate assembly guide.
Important!
- When splicing and connecting, T-Flex Sealing Tape should be used.
- The width of the sill insulation must always at least match the width of the overlying sill board.
- Storage should be done in a way that protects the product from UV radiation and heat (< +35 ˚C) as this shortens the product's lifespan.
This product is evaluated and registered with the following entities:
Declared item in Supply Chain Declaration Portal (SCDP) for New buildings gen. 4.- Registered in the Swan's house product portal
This product is evaluated and registered with the following entities.
Articles
- Name Art.nr Specification
Technical specification
- Material: Expanded and extruded LD polyethylene (LDPE)
- Density: 30 kg (SS-EN 1602)
- Thickness: 7 mm
- Aging resistance: (alkali) At least 50 years (SP-0414)
- Vapor tightness (approx.): 2000 x 10³ s/m (SP-2706)
- Waterproofness: Sealed (EN 1928)
- Recommended installation temperature: -20 to +40 ˚C
Accessories for T-Syll
